The Day I Stopped Confusing Windows Service, Kestrel, and HTTP.sys

A real developer story — with real production decisions, real failures, and real fixes

I used to think these three were basically the same topic:

• Windows Service

• Kestrel

• HTTP.sys

I thought:

“They’re all just ways to host my .NET API, right?”

That misunderstanding cost me a full day in debugging.

Because they are not the same layer.

They solve different problems.

And until you understand the layering, you’ll keep building apps that run on your laptop… but fail on the server.

This is my real story of how I finally understood it — and how you can implement each one properly.

For content overview videos
https://www.youtube.com/@DotNetFullstackDev

The real requirement that started it all

My project had a very normal enterprise requirement:

1. Every night, files are dropped into a folder (CSV/Excel)

2. A service should pick them up, validate them, and push them into SQL

3. Operations team wants a simple internal API endpoint:

   • “What files were processed today?”

   • “What failed?”

   • “How many rows were inserted?”

4. The server is Windows.

5. Nobody wants IIS complexity unless needed.

6. Security team later asks: “We want Windows authentication.”

So I ended up using all three:

• Windows Service (for the worker)

• Kestrel (for a simple API)

• HTTP.sys (when Windows-auth + enterprise constraints came in)

---

Part 1 — Windows Service (Worker)

Why I needed it (and why console apps are a trap)

My first build was a console app.

It ran perfectly.

But the moment I:

• closed the window

• logged out

• restarted the server

…the processing stopped.

That’s when I learned the key difference:

A console app is “someone running it”.

A Windows Service is “Windows running it”.

A Windows Service is designed for:

• automatic start at boot

• running without a logged-in user

• clean stop/restart control

• monitoring and recovery rules

Basically: production reliability.

---

Implementation — Step-by-step with real explanations

Step 1 — Create a Worker Service project

dotnet new worker -n FileProcessorService
cd FileProcessorService

Why this template?
Because this template is not “just code that runs.” It gives you:

• a hosted lifecycle (start/stop)

• built-in dependency injection

• structured logging

• a background processing model designed for servers

This is the correct base for anything that must run 24/7.

---

Step 2 — Add Windows Service integration

dotnet add package Microsoft.Extensions.Hosting.WindowsServices

What does this package actually do?
Without this package, your worker is just a normal .NET process.

With this package:

• your app understands Windows Service Control Manager (SCM)

• it receives Start, Stop, Shutdown signals properly

• it behaves like a real service (not like a console app pretending to be one)

This is the difference between:

• “I can run it”
  and

• “IT can operate it”

---

Step 3 — Configure Program.cs (and why each line matters)

using Microsoft.Extensions.Hosting;
using Microsoft.Extensions.Logging;

IHost host = Host.CreateDefaultBuilder(args)
    .UseWindowsService(options =>
    {
        options.ServiceName = "FileProcessorService";
    })
    .ConfigureLogging(logging =>
    {
        logging.ClearProviders();
        logging.AddConsole();   // useful during local debugging
        logging.AddEventLog();  // useful when running as service
    })
    .ConfigureServices(services =>
    {
        services.AddHostedService<Worker>();
    })
    .Build();

await host.RunAsync();

Let me explain what’s happening here like I wish someone explained to me:

• CreateDefaultBuilder sets up the standard hosting environment:

  • configuration (appsettings.json + environment variables)

  • dependency injection container

  • logging pipeline

• UseWindowsService tells the host:

  • “Don’t run like a console app”

  • “Run as a Windows service with SCM integration”

• Logging:

  • AddConsole() helps you when you run locally (dotnet run)

  • AddEventLog() is critical because once it runs as a service, you won’t see console output.
    Without EventLog, you’ll feel blind in production.

---

Step 4 — Write Worker.cs correctly (this is where most people mess up)

using Microsoft.Extensions.Hosting;
using Microsoft.Extensions.Logging;

public sealed class Worker : BackgroundService
{
    private readonly ILogger<Worker> _logger;

    public Worker(ILogger<Worker> logger) => _logger = logger;

    protected override async Task ExecuteAsync(CancellationToken stoppingToken)
    {
        _logger.LogInformation("Service started at {time}", DateTimeOffset.Now);

        while (!stoppingToken.IsCancellationRequested)
        {
            try
            {
                _logger.LogInformation("Checking folder for new files...");
                ProcessFiles();
            }
            catch (Exception ex)
            {
                _logger.LogError(ex, "File processing failed");
            }

            await Task.Delay(TimeSpan.FromMinutes(5), stoppingToken);
        }

        _logger.LogInformation("Service stopping at {time}", DateTimeOffset.Now);
    }

    private void ProcessFiles()
    {
        // Real implementation:
        // - scan folder
        // - lock file while processing
        // - validate and parse rows
        // - insert into SQL
        // - move file to Processed/Failed folders
    }
}

Why the CancellationToken matters so much?
Because when Windows stops a service, it doesn’t “kill it immediately.”
It sends a stop request.

If your code ignores cancellation:

• your service takes too long to stop

• it may get force-killed

• it may corrupt processing state

This is how production issues happen.

---

Step 5 — Publish for deployment

dotnet publish -c Release -r win-x64 --self-contained false -o C:\Services\FileProcessorService

Why publish?
Because servers should not build your project.
Servers should run compiled artifacts.

Publishing creates the final executable + dependencies in a clean folder.

---

Step 6 — Install as Windows Service

PowerShell (Admin):

New-Service `
  -Name "FileProcessorService" `
  -BinaryPathName "C:\Services\FileProcessorService\FileProcessorService.exe" `
  -DisplayName "File Processor Service" `
  -StartupType Automatic

Now Windows owns it.

Your app becomes an operating system-managed process.

---

Step 7 — Start and validate

Start-Service FileProcessorService
Get-Service FileProcessorService

Then check logs:

• Windows Event Viewer → Windows Logs → Application

This step matters because:

• most failures happen at startup due to config/path permissions

• EventLog is where you’ll find the truth

---

Part 2 — Kestrel (Web API)

Why I used it first for the internal status API

Once the worker was stable, Ops team asked:

“Can we have an endpoint to see status?”

I didn’t need enterprise auth initially.
I just needed:

• /health

• /processed-files/today

• /failed-files/today

For this, Kestrel is perfect.

What Kestrel really is

Kestrel is the default web server inside ASP.NET Core.

It is:

• fast

• modern

• easy

• cross-platform

It listens directly on a port like

http://localhost:5070

.

---

Implementation — Step-by-step with explanation

Step 1 — Create Web API

dotnet new webapi -n FileStatusApi
cd FileStatusApi

Step 2 — Make it run as Windows Service

dotnet add package Microsoft.Extensions.Hosting.WindowsServices

Step 3 — Configure Program.cs

var builder = WebApplication.CreateBuilder(args);

builder.Host.UseWindowsService(options =>
{
    options.ServiceName = "FileStatusApiService";
});

builder.Services.AddControllers();

var app = builder.Build();

app.MapGet("/health", () => Results.Ok("OK"));
app.MapControllers();

app.Run();

Key understanding:
Windows Service here controls lifetime.
Kestrel controls HTTP serving.

Different jobs. Same process.

---

Step 4 — Set explicit port (don’t gamble)

appsettings.json:

{
  "Kestrel": {
    "Endpoints": {
      "Http": {
        "Url": "http://localhost:5070"
      }
    }
  }
}

Why explicit?
In production you need predictability:

• firewall rules depend on known ports

• monitoring depends on known endpoints

• avoiding port collisions requires control

---

Step 5 — Publish & install like earlier

dotnet publish -c Release -r win-x64 -o C:\Services\FileStatusApi

New-Service `
  -Name "FileStatusApiService" `
  -BinaryPathName "C:\Services\FileStatusApi\FileStatusApi.exe" `
  -StartupType Automatic

Test:

• http://localhost:5070/health

At this point, I thought: “Done.”

Then security came in.

Keep the Momentum Going — Support the Journey

If this post helped you level up or added value to your day, feel free to fuel the next one — Buy Me a Coffee powers deeper breakdowns, real-world examples, and crisp technical storytelling.

---

Part 3 — HTTP.sys

Why Kestrel wasn’t preferred in my enterprise environment

Security requirement changed everything:

“Use Windows Authentication. Domain users only.”

Now, yes — you can do Windows Auth with Kestrel, but in many enterprises:

• infrastructure teams prefer OS-level HTTP handling

• they want URL reservations

• they want certificate bindings controlled centrally

• they want kernel-mode handling

That’s where HTTP.sys comes in.

What HTTP.sys really is

HTTP.sys is Windows’ own HTTP stack.

It’s not “a library web server.”
It is an OS feature.

That means:

• Windows controls the port

• Windows controls auth

• Windows controls TLS binding

Your app hooks into it.

---

Implementation — Step-by-step with explanation

Step 1 — Enable HTTP.sys hosting in Program.cs

using Microsoft.AspNetCore.Server.HttpSys;

var builder = WebApplication.CreateBuilder(args);

builder.WebHost.UseHttpSys(options =>
{
    options.UrlPrefixes.Add("http://localhost:5090");

    options.Authentication.Schemes =
        AuthenticationSchemes.Negotiate |
        AuthenticationSchemes.NTLM;

    options.Authentication.AllowAnonymous = false;
});

var app = builder.Build();

app.MapGet("/secure", (HttpContext ctx) =>
{
    return $"Hello {ctx.User.Identity?.Name}";
});

app.Run();

What this does:

• Requests authentication at the OS HTTP layer

• Your API automatically sees the authenticated user

• No tokens, no login screen, no custom auth middleware required

---

Step 2 — The critical step: URL reservation (URLACL)

netsh http add urlacl url=http://localhost:5090/ user=Everyone

Why is this needed?
HTTP.sys protects URL prefixes.
If your service runs under a normal account, Windows may block it from binding that URL unless reserved.

Without this:

• service might fail on start

• you’ll waste time blaming your code

• but the problem is OS permission

---

Step 3 — Publish & install as service

Same as before.

Test:

• http://localhost:5090/secure

• It should return your domain identity automatically.

---

👉 I’ve shared the JWT Authentication Boilerplate for ASP.NET Core (.NET 8)
(Instant download, production-ready, no fluff)

Final clarity — the mental model I now use

If you remember only this, you’ll never get confused again:

Windows Service = “How my app runs”

Kestrel = “How my app serves HTTP (cross-platform)”

HTTP.sys = “How Windows serves HTTP (OS-level)”

Different layers.

Not competitors.
